Short Description:

Metal Raschig ring is the oldest regular packing and is still used today for many applications in mass transfer applications but commonly for refilling existing columns.Friedrich Raschig invented the rings in the 1880s but did not patent them until the 1910s. Due to simple cylindrical shaped tube with an aspect ratio of 1:1, liquid liquid will move in the thousands of channels formed by the rings, coating the inside and outside surfaces, and eventually flowing to the bottom. Gas entering at the bottom will flow through the same paths formed by the rings, and will have time to contact and react with the liquid.However, Owing to metal Raschig ring’s inside is a cylinder with open ends, it is difficult to follow into Metal Raschig Ring’s inside for liquid. Finally, its mass transfer efficiency is lower than others. It has replaced by Metal Pall ring slowly.

Technical Parameter

D×H×δ mm	Specific area m²/m³	Void rate %	Bulk number Pieces/m³	Package density Kg/m³
15×15×0.3	350	95	230000	380
15×15×0.5	350	92	230000	600
25×25×0.5	220	95	50000	400
25×25×0.8	220	92	50000	600
35×35×0.8	150	93	19000	430
50×50×0.8	110	95	6500	321
80×80×1.2	65	96	1600	300

Trade Details

Related Trade Information
HS Code	8419909000
Package	1: Two Super sacks on Fumigation Pallet 2: 100L plastic woven bag on Fumigation Pallet 3: 500500500 mm carton on Fumigation Pallet 4: Upon your requirement
Process Method	Stamping
Material	Carbon steel,Stainless steel, Alloy,Copper,Duplex,Aluminum,Titanium,Zirconium and so on
Typical Application	Ethanol,Biodiesel,CO2 and H2S selective absorption,Air pollution control scrubbers,Water deaeration and decarbonation
Production time	7 days against one 20GP container loading quantity
Executive standard	HG/T 4347-2012,HG/T 21556.1-1995 or refer to your detailed requirement
Sample	Free samples within 500 Grams
Other	Accept EPC turnkey,OEM/OEM,Mold Customization,Installation&Guidance,Test, Entrusted design service etc.

Typical Application

1: Used in petrochemical engineeing for catalyst support

2: Used in water treatment for separation and desorption

3: Used in petrochemical industry for distillation and extraction

4: applied in refineries,petrochemical induistries, combution plants and chemical industries

5: applied in deethanizer,demethanizers and quencth tower

Feature

1: Simple structure, large void ratio

2: High crushing strength

3: Uniformly layered with less probability of breakage

4: High corrosion resistance

5: Easy handling

6: Applicable to columns of relatively large diameters

Ayrtter mainly developed in mass transfer product, tower internals, wastewater treatment filler, VOCS series, cooling tower filler, random & structured packing, EPC project and on. Furthermore, owned 2 international patents and 5 Chinese patents on the development journey.
