Short Description:

Dixon ring of hysteresis is higher than the similar entity packing, surface wetting condition is better than general porcelain ring too, thus its film formation rate is higher, and separation efficiency is also higher. The theoretical plate number of Dixon packing is increased with the increase of gas velocity, and at the same time, lower with reducing of the surface wetting rate of packing.

Product Detail

Dixon ring is a kind of small particles and high efficient packing which is made of metal wire mesh; the diameter of packing is equal to its height.

Dixon ring is mainly used in laboratory and separation process of small batch, high purity products. The pressure drop of packing is related with gas velocity, liquid spray quantity, material, surface tension, viscosity, the characteristics of the packing, and the flooding capacity at the same time.

Dixon ring

Parameter table

Dixon ring data:

Specification (mm)	Net Item	Tower Diameter (mm)	Theoretical Plate (PCS/m)	Bulk Density (kg/m3)	Surface Area (m2/m3)
Φ2×2	100	Φ20-35	50-60	670	3500
Φ3×3	100	Φ20-50	40-50	520	2275
Φ4×4	100	Φ20-70	30-40	380	1525
Φ4×5	100	Φ20-100	20-30	295	1180
Φ6×6	80	Φ20-150	17-20	280	1127
Φ7×7	80	Φ20-200	14-17	265	1095
Φ8×8	80	Φ20-250	11-14	235	987
Φ9×9	80	Φ20-300	8-11	200	976
