Metal Wire Triangular is reflected in its efficient mass and heat transfer capabilities. Its triangular structure creates a large number of voids and channels inside the packing, which is conducive to the uniform distribution and thorough mixing of fluids in the packing. At the same time, the spiral arrangement allows the packing to present a spiral structure in the reactor, enhancing the turbulence of the fluid and thus improving mass and heat transfer efficiency.
Metal Wire Triangular Specification:
| Spec (mm) | Tower Diameter (mm) | Theoretical plate (PCS/m) | Material | Operating pressure |
| 1.75×1.75 | 50 | 60-70 | Benzene, CCl4 | Normal pressure |
| 2.5×2.5 | 50 | 60-70 | Benzene, CCl4 | Normal pressure |
| 3×3 | 18 | 50-80 | Benzene, CCl4 | Normal pressure |
| 4×4 | 50 | 25-40 | Benzene, CCl4 | Normal pressure |
| 5×5 | 50 | 20-30 | Benzene, CCl4 | Normal pressure |
| 6×6 | 82 | 14-20 | Ammonia | 3kg/cm2 absolute pressure |
| 7×7 | 82 | 11-13 | Ammonia | 3kg/cm2 absolute pressure |
| 7×7 | 96 | 8-10 | N-Heptanes, Toluene | Normal pressure |
| 8×8 | 82 | 10-11 | Ammonia | 3kg/cm2 absolute pressure |
